Zunt - Monolithic Insulating Joints
|
|
|
|
Monolithic Insulating Joints
with flanged ends
-
PRODUCTION RANGE
| SIZE |
from ½" up to 100" and over |
| RATING |
from ANSI 150 to ANSI 2500, API 10000 and over |
| FLANGES |
WN RF or RJ flanges of any type |
TECHNICAL FEATURES
| Design Temperature |
-29°C / + 120°C |
| Dielectric Strength Test |
3 kV for 1 min. 50 Hz AC (higher on request) |
| Electrical Resistance Test |
> 100 MOhm 1000 V DC |
MATERIALS & COMPONENTS
Materials and components are selected to match the specified operating conditions, the
fluids conveyed, etc, in accordance with the client’s requirements
|
